It has been reported that the charge transport in the blend depends directly on the effective vertical as well as the lateral phase segregation of the polymer and fullerene domains within the blend Quiles et al. The charge extraction process is improved when the donor polymer domains segregate toward the anode interface and the acceptor fullerene domains segregate toward the cathode interface Heutz et al.

Such combination of vertical and lateral phase segregated morphology favors the charge transport across the blend and across the interfaces, thus improving the device performance. Apart from improved charge extraction, the inverted device structure allows for the replacement of both the low work function metal cathode and the PEDOT:PSS HTL, which are responsible for the degradation of the device, and thus improving the device lifetime Sahin et al.

For example, it has been shown that P3HT does not block the electron conduction but PCBM is known to significantly block the hole conduction through the blend Germack et al. Nevertheless, this was not observed Wang H. With such reverse interfacial segregation of the active layer, it was expected that the device would exhibit high series resistance due to the hole blocking by PCBM at the anode, leading to a reduced device performance. The degree of the vertical phase segregation depends on the nature of the substrate and spin coating conditions, and can also be controlled using thermal annealing or by changes in the blend-substrate interface by the modification of the substrate surface energy Quiles et al.

This is shown in Figure 5 , where the depth profile of PCBM in the blend was measured by ellipsometry, and investigated under several fabrication conditions. In contrast, it is larger for the blend spin-coated on fused silica substrates and is enhanced by thermal annealing Figure 5A. In this latter case, the depth profiles suggest that the free surface is enriched of PCBM clusters, a fact that is confirmed by in situ optical microscopy during thermal annealing. Furthermore, as can be seen in Figure 5D , the deposition of a molecular self-assembled monolayer of hexamethyldisilazane on the substrate modifies its surface energy, leading to a change in the direction of compositional gradient of PCBM in the blend, with the film enriched of P3HT domains toward the substrate while PCBM is displaced toward the free surface Quiles et al.

Reprinted by permission from Macmillan Publishers Ltd Quiles et al. One study has used NR for analyzing the compositional profiles of the layers along the depth of the device to reveal the influence of the different capping metal electrodes as well as the addition of the solvent additive nitrobenzene on the thermal stability of the device Mauger et al. The same study has also further reported that changes in the compositional profiles due to the thermal annealing can be due to a specific charge transfer or doping process occurring between the metal electrodes and PCBM due to differences in their Fermi Levels Mauger et al.

It has been shown that doping and charge transfer occurs more strongly with Ca than Al, leading to differences in the vertical phase segregation and the compositional profiles depending upon the type of the electrode Mauger et al. In contrast, it was found that the solvent additive can lead to a significant reduction in both the vertical phase segregation and the concentration of PCBM at the interface. The interfacial layers may influence both the energy level alignment and the vertical phase segregation within the device, which affect the device performance.

The study has demonstrated by employing ultraviolet photoelectron spectroscopy UPS that the observed difference in the device performance for each of these three donor polymers is not due to a hole extraction barrier for the PTB7 device Oehzelt et al. Such inverted polymer solar cell devices have shown an improvement in the efficiency from 7. The concept of barriers for injection and extraction of charge carriers, or simply, the energy barriers, arises from the difference in chemical potential or Fermi energy—E F between two dissimilar materials when they are joined together.

Upon contact, electron transfer will occur at the interface until the chemical potential becomes the same throughout the materials. In Figure 6A is shown the case of a metal whose Fermi level before contact is below that of the organic semiconductor. After joining them, electron transfer from the organic material to the metal will occur, until the Fermi level is the same throughout the materials.

Similarly, if the Fermi level of the metal before contact is higher than that of the semiconductor, there will be electron transfer to the semiconductor LUMO, as illustrated in Figure 6B. A Fermi level of metal is below that for the organic semiconductor, before contact. B Same as A , but for the Fermi level of metal below that for the organic semiconductor.

Organic Solar Cells - Materials Devices Interfaces And Modeling Hardcover

This difference in the energy levels has been termed as an energy barrier if a given carrier must have its energy increased from one material to another, as it crosses the interface. Thus, an energy barrier would depend on the energy levels of the materials, on which carrier is being considered and also on which direction it is being transported. This energy difference may either allow or prevent the movement of charge carriers across the interface depending upon the magnitude of the energy difference and the direction of the movement of the charge carriers.

Therefore, in some cases there could be a barrier for carrier injection, but not for extraction across the same interface. Several studies have investigated in different ways the influence of the injection and extraction barriers on the device performance Pfeiffer et al. The effect of the energy barriers in general is to hinder the transfer of the charge carriers across the interfaces, significantly affecting the electrical characteristics of the devices. The physical mechanisms which are related to this charge transfer process and its effect on the J-V curves have been explained in these studies.

These FHJ solar cells consist of the separate layers of donor polymer and acceptor molecule, in contrast with BHJ solar cells where a layer of the blend of the donor polymer and acceptor molecule is deposited to form the nanostructured active layer of the device. The n-type materials form ohmic contacts with the metals having lower work functions, while they yield rectifying contacts with metals having higher work functions. In case of the p-type materials, the opposite effect is exhibited. Photovoltaic response was observed, albeit with a much lower V oc than expected from the materials Fermi levels.
